DH-PFS3210-8GT2GF-96 -Switch with8-Port PoE

> 100 Mbps PoE ports and gigabit uplink ports.

> The red port meets the IEEE 802.3bt standard.

> Power supply supports up to 90 W.

> PoE watchdog monitors the status of terminals in real-time.

> Supports 250 m long-distance power supply.

> Supports the power management policy.

> 8-pin PoE offers better compatibility and reduces cable loss.

> Durable full-metal housing provides great heat dissipation.

Category: PoE Switches

Description

DH-PFS3210-8GT2GF-96 -Switch with8-Port PoE

CONTAACT US FOR MORE DITALIES

Hardware

Included Power Adapter

Yes

PoE

Yes

Ethernet Port

8

Ethernet Port Speed

10/100 Mbps

Ethernet Port Uplink Speed

10/100/1000 Mbps

Optical Port Uplink Speed

1 Gbps

Description of Function Slots

Port 1-8: 8 × 10/100 Base-T (PoE)
Uplink 1: 1 × 10/100/1000 Base-T
Uplink 2: 1 × 1000 Base-X

Power Supply

53 VDC, 1.81 A

Operating Temperature

–10 °C to +55 °C (+14 °F to +131 °F)

Operating Humidity

10%–90% (RH)

Storage Temperature

–40 °C to +70 °C (–40 °F to +158 °F)

Storage Humidity

5%–95% (RH)

Power Consumption

Idling: 3 W
Full load: 96 W

Performance

Layer

Unmanaged

Management Type

No

Smart Managed Switch

No

MTBF

105.24 year

Switching Capacity

5.60 Gbps

Packet Forwarding Rate

4.17 Mpps

Packet Buffer Size

4 Mbit

Jumbo Frame

9K Byte

MAC Table Size

8K

Communication Standard

IEEE802.3; IEEE802.3u; IEEE 802.3ab; IEEE802.3x

PoE

PoE Protocol

IEEE 802.3af; IEEE 802.3at; Hi-PoE; IEEE 802.3bt

PoE Power

Port 2-8 ≤30 W, port 1 ≤90 W, total ≤96 W

PoE Power Consumption Management

Yes

PoE Pin Assignment

1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)

Long Distance PoE Transmission

Yes

General

Statics Protection

Air discharge: 8 kV
Contact discharge: 6 kV

Lighting Protection

Common mode: 4 kV
Differential mode: 2 kV

Net Weight

0.65 kg (1.43 lb)

Gross Weight

1.4 kg (3.09 lb)

Product Dimensions

240 mm × 105 mm × 28 mm (9.45″ × 4.13″ × 1.10″)

Packaging Dimensions

279 mm × 239 mm × 89 mm (10.98″ × 9.41″ × 3.50″)

Casing Material

Metal

Installation

Desktop mount

Certifications

CE; FCC

Installation

Transmission Performance:
Switch power supply voltage 53V. CAT5E/CAT6. Max. DC resistance < 10 Ω/100 m
Cable(m)	Load Capacity(W)	Bandwidth(Mbps)
IEEE802.3bt 90 W
100	71.3	100
150	62	10
200	51	10
250	40	10
Hi-PoE 60 W
100	53	100
150	50	10
200	47	10
250	37	10
IEEE802.3at 30 W
100	25.5	100
150	25.5	10
200	25.5	10
250	25.5	10
Note: Data from this table was collected by Dahua test lab and is for reference only . The actual transmission distance may vary due to power consumption of connected devices or the cable type and status.
