PFM923I-5EUN-C

305m LSZH UTP CAT6 Cable – Oxygen free copper (99.97% purity)

> 305.0 m (1000 ft)/carton UTP CAT6, power over Ethernet, compatible with one cable

> High-purity Oxygen-Free Copper conductor material

> Customized LSZH outer sheath; meet CE CPR Eca or ANSI UL CM flame retardant class certified

> 10-year warranty

Category:

Always happy to help !

Get a quote for this product
Or inquire about anything, and our customer service will respond to you immediately


Conductor
MaterialOxygen free copper (99.97% purity)
Diameter0.57 mm ± 0.01 mm(0.0224″±0.0004″)
American Wire Gauge23AWG
Insulation
MaterialHDPE
Min. Average Thickness0.21 mm(0.0082″)
Diameter1mm±0.05mm(0.0393″±0.0019″)
Color (4 Pairs)Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown
Separator
MaterialPE
SpecificationTranslucent 4.5 × 0.4 mm
Rip Cord
MaterialPolyester
Specification500D
Sheath
MaterialLSZH
Min. Average Thickness0.43 mm (0.0169″)
Diameter6.3 mm ± 0.5 mm (0.2480″±0.0196″)
ColorOrange
Electrical
Max. DC Resistance of a Single Conductor9.38Ω/100 m
Min. Insulation Resistance5000MΩ·km
Max. DC Resistance Unbalance≤5%
Dielectric StrengthNo breakdown with 1KV DC for 1 min
Transmission
Characteristic Impedance (1-250MHz)100 ± 15Ω
Mechanical
Tensile StrengthSheath≥10 MPa, insulation≥16 MPa
Elongation at BreakSheath≥125%, insulation≥300%
Installation Bending Radius>8 times of outer cable diameter
Conductor Elongation at Break≥10%
Environmental
Shrinkage of Insulation≤5%
Color Migration Resistance of InsulationNo migration
Sheath Tensile Strength and Elongation at Break after Aging≥8 MPa, ≥100%
Low Temperature Bending TestNo cracking after the test
Heat Shock TestNo cracking after the test
Operation Temperature–20°C to +60°C (–4°F to 140°F)
Installation Temperature0°C to +50°C (32°F to 122°F)
Storage Temperature and Humidity–10°C to +40°C (14°F to 104°F), <60% (RH)
Certification
CertificationCPR Eca
