PFM920I-6F-C

Conductor

Material

Oxygen free copper (99.97% purity)

Diameter

0.57 mm ± 0.02mm(0.0224″±0.0007″)

American Wire Gauge

23AWG

Insulation

Material

HDPE

Min. Average Thickness

0.27 mm(0.0106″)

Diameter

1.12 mm ± 0.06 mm(0.0441″±0.0023″)

Color (4 Pairs)

Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown

Separator

Material

PE

Specification

Translucent 5.2 mm × 0.7 mm (0.2047″× 0.0275″)

Rip Cord

Material

Polyester

Specification

500D

Shielding

Material

Aluminum foil

Specification

25×0.063mm (25× 0.0025″)

Sheath

Material

PVC

Min. Average Thickness

0.55 mm(0.0216″)

Diameter

7.3 mm ± 0.4 mm(0.2874″±0.0157″)

Color

Gray

Electrical

Max. DC Resistance of a Single Conductor

9.5Ω/100 m

Min. Insulation Resistance

5000MΩ·km

Max. DC Resistance Unbalance

2% (pair intra), 4% (pairs inter)

Dielectric Strength

No breakdown with 1KV DC for 1 min

Transmission

Characteristic Impedance

100 ± 15Ω

Near End Cross Talk

≥33.10 dB/100 m@250 MHz

Max. Attenuation

32.8 dB/100 m@250 MHz

Return Loss

≥17.3 dB/100 m@250 MHz

Mechanical

Tensile Strength

Sheath≥13.5 MPa, insulation≥16 MPa

Elongation at Break

Sheath≥150%, insulation≥300%

Installation Bending Radius

>8 times of outer cable diameter

Conductor Elongation at Break

≥10%

Environmental

Shrinkage of Insulation

≤5%

Color Migration Resistance of Insulation

No migration

Sheath Tensile Strength and Elongation at Break after Aging

≥13.5 MPa, rate of change≤20%

Low Temperature Bending Test

No cracking after the test

Heat Shock Test

No cracking after the test

Operation Temperature

–20°C to +60°C (–4°F to 140°F)

Installation Temperature

0°C to +50°C (32°F to 122°F)

Storage Temperature and Humidity

–10°C to +40°C (14°F to 104°F), <60% (RH)

Packaging

Length

305.0 m (1000.66 ft) ± 2.0 m ( ft)

Packaging Dimensions

400mm×400mm×310mm (15.74″x15.74″x12.20″) (L × W × H)

Packaging Method

305.0 m (1000.66 ft) a carton

Net Weight

15.6kg±0.6kg ( 34.39lb±1.32lb)

Executive Standard

Executive Standard

ANSI/TIA 568-C.2

Certification

Certification

CPR Eca
