PFM920I-5EF-C

Conductor

Material

Oxygen free copper (99.95% purity)

Diameter

0.52 mm ± 0.02mm(0.0204″±0.0007″)

American Wire Gauge

24AWG

Insulation

Material

HDPE

Min. Average Thickness

0.25 mm(0.0098″)

Diameter

1.04 mm ± 0.05 mm(0.0409″±0.0019″)

Color (4 Pairs)

Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown

Rip Cord

Material

Polyester

Specification

500D

Drain Wire

Material

Solid tinned copper

Specification

0.50 mm ± 0.10 mm(0.0196″±0.0039″)

Shielding

Material

Polyester aluminum foil

Specification

19×0.065mm (19 × 0.0025“)

Sheath

Material

PVC

Min. Average Thickness

0.40 mm(0.0157″)

Diameter

6.2 mm ± 0.5 mm(0.2440″±0.0196″)

Color

Gray

Electrical

Max. DC Resistance of a Single Conductor(20℃)

9.5Ω/100 m

Insulation Resistance

5000MΩ·km

Max. DC Resistance Unbalance

2% (pair intra), 4% (pairs inter)

Unbalanced line-to-ground capacitance

160pF/100m

Working Capacitance

56pF/100m

Transmission

Characteristic Impedance

100 ± 15Ω

Near End Cross Talk

≥35.30 dB/100 m@100 MHz

Max. Attenuation

≤22.0 dB/100 m@100 MHz

Return Loss

≥20.1 dB/100 m@100 MHz

Mechanical

Tensile Strength

Sheath≥13.5 MPa, insulation≥16 MPa

Elongation at Break

Sheath≥150%, insulation≥300%

Installation Bending Radius

>8 times of outer cable diameter

Environmental

Color Migration Resistance of Insulation

No migration

Low Temperature Bending Test

No cracking after the test

Heat Shock Test

No cracking after the test

Operation Temperature

–20°C to +75°C (–4°F to 167°F)

Installation Temperature

0°C to +60°C (32°F to 140°F)

Storage Temperature

–15°C to +75°C (5°F to 167°F)

Packaging

Length

305.0 m (1000.66 ft) ± 2.0 m (6.56ft)

Packaging Dimensions

350mm×350mm×300mm (13.77″x13.77″x11.81″) (L × W × H)

Packaging Method

305.0 m (1000.66 ft) a roll, plywood wooden shaft

Gross Weight

14kg±0.5kg (30.86 lb±1.10lb)

Net Weight

11.5kg±0.5kg ( 25.35lb±1.10lb)

Executive Standard

Executive Standard

ANSI/TIA 568-C.2

Certification

Certification

CPR Eca
